Motion Control Engineering Motion 4000 User Manual

PC Board Quick References
5-49
5
Motion 4000
UP Up direction is picked
DN Down direction is picked
CAR DOOR
BYPASS
Car door bypass is active
HOISTWAY
DOOR BYPASS
Hoistway door bypass is active
SAFS SAFS relay is picked
SAFL SAFL relay is picked
Table 5.5 HC-CTL Board Jumpers
Jumper Description
JP1 Fault Bypass: Open
JP3 SPA Hard Reset: Jumper required only to perform 2K testing
JP4 SPB Hard Reset: Jumper required only to perform 2K testing
JP6 SPC Hard Reset: Jumper required only to perform 2K testing
Table 5.6 HC-CTL Board Fuses
Fuse Description
F2S 2S bus fuse
F2HA F2HA bus fuse
F2 F2 bus fuse
Table 5.4 HC-CTL Board Indicators
Indicator Description
