Motion Control Engineering Motion 4000 User Manual

PC Board Quick References
5-55
5
Motion 4000
Table 5.15 HC-RDR Board Terminals
Connector Terminal Description
J1 DOBR Door Open Button Rear (input)
DCBR Door Close Button Rear (input)
PHER Photo Eye Rear (input)
SER Safety Edge Rear (input)
DPMR Door Position Monitor Rear (input)
DOLR Door Open Limit Rear (input)
DCLR Door Close Limit Rear (input)
22 Bus
2S 2S Bus
2S 2S Bus
J2 GSR1 Gate Switch String from front doors (output)
GSR2 Gate Switch String from front doors (input)
DZR1 Door zone string from front doors (output)
DZR2 Door zone string from front doors (input)
11 Bus
2S 2S bus feed (MCE wiring)
DO1R Rear door open function (output)
DCPR Door close power, rear.
DCFR Rear door close function (output)
N1R Nudging operation (output)
COMR Common for DO1R, DCPR, DCFR, N1R
J4 BABR Bottom access rear door lock bypass (input)
- No connection
DLATR Rear top door lock (input)
- No connection
DLABR Rear bottom door lock (input)
- No connection
DCABR Rear bottom retiring cam door lock (input)
- No connection
DCATR Rear top retiring cam door lock (input)
- No connection
DCMSR Rear middle retiring cam door lock (input)
- No connection
GSR Rear gate switch (input)
- No connection
GEDR Rear gong enable down (output)
GEUR Rear gong enable up (output)
J8 Used to program the SPA microcontroller
J9 Used to program the SPB microcontroller
