J11 TABR Top Access Rear Door Lock Bypass (input)
DOBR Door Open Button Rear (input)
DCBR Door Close Button Rear (input)
PHER Photo Eye Rear (input)
SER Safety Edge Rear (input)
DPMR Door Position Monitor Rear (input)
DOLR Door Open Limit Rear (input)
DCLR Door Close Limit Rear (input)
DZR Door Zone Rear (input)
2S 2S bus (output)
2S 2S bus (output)
Table 5.16 HC-RDR Board Indicators
Indicator Description
DOFR Door open function rear input is high
DCFR Door close function rear input is high
DCPR Door close power rear input is high
TABR Top access rear door lock bypass input is high
DOBR Door open button rear input is high
DCBR Door close button rear input is high
PHER Photo eye rear input is high
SER Safety edge rear input is high
DPMR Door position monitor rear input is high
DOLR Door open limit rear input is high
DCLR Door close limit rear input is high
DZR Door zone rear input is high
BABR Bottom access rear door lock bypass input is high
DLABR Rear bottom door lock input is high
DCABR Rear bottom retiring cam door lock input is high
GSR Rear gate switch input is high
MABGR Access Bypass Gate Rear monitor signal
MABBR Access Bypass Bottom Rear monitor signal
MABTR Access Bypass Top Rear monitor signal
2S 2S bus is high
NUDGR Nudge rear output on
DS1 Rear Car Door Bypass
DS2 Rear Hoistway Door Bypass
DS4 SPA
DS24 SPB
Table 5.15 HC-RDR Board Terminals
Connector Terminal Description
