Motion Control Engineering Motion 4000 User Manual

PC Board Quick References
5-57
5
Motion 4000
Table 5.17 HC-RDR Board Test Points
Test Points Description
GND 0V
+5V +5 Vdc measured between this test point and TP GND.
+25V Unregulated 25Vdc from the HC-CHP board
11 Bus (common)
2 2 Bus (120 Vac)
2S 2S Bus
19 120Vac = Car Door Bypass (input) is ON
20 120Vac = Hoistway Door Bypass (input) is ON
33 120Vac = Access Bypass gate (output) is ON
42 120Vac = Access Bypass Top (output) is ON
43 120Vac = Access Bypass Button (output) is ON
44 120Vac = Gate Switch Bypass (output) is ON
45 120Vac = Hoistway Door Bypass (output) is ON
46 120Vac = Top Access Bypass (output) is ON
47 120Vac = Bottom Access Bypass (output) is ON
48 120Vac = Gate Switch Relay is ON
49 120Vac = Door Lock Relay is ON
