PC Board Quick References
5-77
5
Motion 4000
Figure 5.15 TC-MPI Motion Processor
Emergency
Brake Reset
Earthquake
Reset
CAN Bus CT
Drive I/F
Discrete
Drive I/F
Discrete
Drive I/F
Encoder
from Drive
Contactor
Proofing, Door
Zone, Spares
Emergency
Brake
Power and
Common
Processor Reset
Buttons
Processor Reset Diagnostic Indicator LEDs
