Appendix
A-28 Manual # 42-02-2P24
R6 Regenerative Drive Reference
This section includes quick reference information for the PowerBack R6 Regenerative AC drive.
Please refer to the R6 Regenerative drive manual provided with the product for detailed expla-
nation of the parameters.
Table A.5 Quick Reference for PowerBack R6 Regenerative Drive
Display Parameter Description Setting Range Resolution
Field/MCE Setting
WARNING: Do not change drive parameters while the elevator is running. Incorrect values can
cause erratic elevator operation.
CP. 0 Password input 0...9999 1 ---
CP. 1 Status display --- --- ---
CP. 2 Main Line Frequency --- 0.1 Hz ---
CP. 3 AC-Phase current L1 --- 0.1 A ---
CP. 4 AC-Phase current L2 --- 0.1 A ---
CP. 5 AC-Phase current L3 --- 0.1 A ---
CP. 6 Actual Load --- 1% ---
CP. 7 Actual Load / peak value --- 1% ---
CP. 8 DC output current --- 0.1 A ---
CP. 9 Actual DC voltage --- 1 V ---
CP.10 DC voltage / peak value --- 1 V ---
CP.11 Heat sink temperature ---
1
0
C
---
CP.12 Overload counter --- 1% ---
CP.13 Active power --- 0.1kW ---
CP.14 Total regen kWhr counter --- 0.1 kWh ---
CP.15 Total motor kWhr counter --- 0.1 kWh ---
CP.16 Total net kWhr counter --- 0.1 kWh ---
CP.17 Apparent power / Line input --- 0.1 kVA ---
CP.18 Analog output 1 / amplification factor -20.00...20.00 0.01 1.00
CP.19 DC bus switching level +/- 30000.00 0.01
Set to 260 for 208 - 240Vac
Set to 600 for 460 - 480Vac
CP.20 Auto error reset counter 0...10 1 3
CP.21 Last Error --- ---
CP.22 Last Error 1 --- ---
CP.23 Last Error 2 --- ---
CP.24 Last Error 3 --- ---
CP.25 Last Error 4 --- ---
CP.26 Last Error 5 --- ---
CP.27 Last Error 6 --- ---
CP.28 Last Error 7 --- ---
CP.29 Software version --- 1.3
CP.30 Software date code DDMM.Y
CP.31 Power part ID code --- 250
CP.32* Pulse off Level -100kW...0.0kW 0.1kW -0.8kW
CP.33* Operating Mode 0...3 1 0
CP.34* Control Angle 0.0...60.0 0.1 29.0
