Motion Control Engineering Motion 4000 User Manual

Factory I/O Assignment, ICE-COP-2 Boards
A-29
A
Motion 4000
Factory I/O Assignment, ICE-COP-2 Boards
COP-2 Board #1 - ID: 0
The first COP-2 board contains standard dedicated inputs as follows:
The first COP-2 board contains standard dedicated outputs as follows:
The first COP-2 board contains standard dedicated car calls (see note) as follows:
COP-2 Board #2 - ID: 1
The second COP-2 board contains standard dedicated car calls (see note) as follows:
Note
Note that the front car calls stack on each other. For example, if a car serves floors 1 through 3,
does not serve floor 4, but does serve floors above 4, floors above floor 4 will move down one
connection rather than leave an I/O open.
IO8IO7IO6IO5IO4IO3IO2IO1
CRO DOB DCB IND FCCC FCS FCHLD FCOFF
IO16 IO15 IO14 IO13 IO12 IO11 IO10 IO9
CGEU CGED SUA SDA FWL FWI NDG PFG
IO24 IO23 IO22 IO21 IO20 IO19 IO18 IO17
108 107 106 105 104 103 102 101
IO8IO7IO6IO5IO4IO3IO2IO1
116 115 114 113 112 111 110 109
IO16 IO15 IO14 IO13 IO12 IO11 IO10 IO9
124 123 122 121 120 119 118 117
IO24 IO23 IO22 IO21 IO20 IO19 IO18 IO17
132 131 130 129 128 127 126 125
