COP-2 Board #3 - ID: 2
The third COP-2 board contains spare inputs as follows:
The third COP-2 board contains spare outputs as follows:
COP-2 Board #4 - ID: 4
The fourth COP-2 board contains standard dedicated inputs as follows:
The fourth COP-2 board contains standard dedicated outputs as follows:
The fourth COP-2 board contains standard dedicated car calls (see note) as follows:
Note
Note that the rear car calls stack on each other. For example, if a car serves floors 1 through 3,
does not serve floor 4, but does serve floors above 4, floors above floor 4 will move down one
connection rather than leave an I/O open.
IO8IO7IO6IO5IO4IO3IO2IO1
- SPIN SPIN SPIN SPIN SPIN SPIN SPIN
IO16 IO15 IO14 IO13 IO12 IO11 IO10 IO9
SPOUTSPOUTSPOUTSPOUT----
IO24 IO23 IO22 IO21 IO20 IO19 IO18 IO17
-----SPOUTSPOUTSPOUT
IO8IO7IO6IO5IO4IO3IO2IO1
CRO DOBR DCBR IND FCCC FCS FCHLD FCOFF
IO16 IO15 IO14 IO13 IO12 IO11 IO10 IO9
CGEUR CGEDR SUA SDA FWL FWI NDGR PFG
IO24 IO23 IO22 IO21 IO20 IO19 IO18 IO17
108R 107R 106R 105R 104R 103R 102R 101R
