Motion Control Engineering Motion 4000 User Manual

Set Up for Construction Operation
2-35
2
Motion 4000
LF.78 Brake drop delay. Time motor will hold full current
and control after direction inputs drop.
sec 0.00 - 3.00 0.50 0.50
LF.79 Current hold time. Delay in turning off the drive
(Delay to turn OFF the motor current after direc-
tion is dropped and LF.78 has expired)
sec 0.1 - 0.5 0.3 0.3
Diagnostic Parameters (Read only)
LF.25 Estimated gear ratio 1
LF.80 Software version -
LF.81 Software date -
LF.82 X2A input state - see tables
in F5 Drive
Manual
LF.83 X2A output state -
LF.86 Operation mode -
LF.87 Actual inverter load (100% = rated load) %
LF.88 Motor command speed rpm
LF.89 Actual motor speed rpm
LF.90 Actual elevator speed ft/m
LF.93 Phase current A
LF.94 Peak phase current A
LF.95 Actual DC voltage V
LF.96 Peak DC voltage V
LF.97 Actual output frequency Hz
O.LF.98 Last error -
US Parameters
US. 1 Password: With different passwords different
parameter groups can be accessed for advanced
programming.
-- - -
US. 3 Load defaults: Select LoAd and press ENTER to
cause all LF parameters to be reset to drive
default values.
-LoAd -
US. 4 Load configuration: Select LoAd and press ENTER
to load the configuration selected in US.10.
-LoAd -
US.10 Select configuration: Selects the drive mode.
ICLSd - Close loop induction
I9LSS = Closed loop induction gearless
PCLSd = Closed loop permanent magnet (PM)
P9LSS = Closed loop PM gearless
-ICLSd
I9LSS
PCLSd
P9LSS
-*
US.34 Analog Pattern Gain - 0.01-20.0 1.0
US. 35 Reference Splitting: This function creates a slope
between two successive serially transmitted speed
values. This parameter should be adjusted for a
time double the actual serial update rate of the
speed command
Note: Program to 40 msec for M4000
mSec 0 –127 mSec 0.0 40
* Parameters are motor / machine / job dependent.
** Recommended but field adjustable.
*** The value is automatically calculated from the motor data or other parameter values.
Parameters for Drive Software Version (LF 80 Drive Software = 1.61 with LF.81 date code = 2801.9 or later)
or (LF 80 Drive Software = 1.71 with LF.81 date code = 704.0 or later.
Table 2.4 TorqMax F5 Parameters
Display Parameter Description Unit Range Default Factory
