Motion Control Engineering Motion 4000 User Manual

Set Up for Construction Operation
2-43
2
Motion 4000
C4 Analog Outputs
Ana Out 1 tb1-33 Terminal 33 Selection - - SPEED
REF
SPEED
CMD
Ana Out 2 tb1-35 Terminal 35 Selection - - SPEED
FEEDBK
SPEED
FEEDBK
Utility U0
U1 Password
Password - - 000000 000000
U2 Hidden Items
Enable or disable hidden parameters
Enable Disable
- - ENABLE ENABLE
U3 Unit
Unit for parameters
English Metric
-- ENGLISHENGLISH
U4 Overspeed Test
Allows overspeed test during inspection
Yes No
- - No No
U5 Restore Dflts
Reset all parameters to default values
U6 Drive Info
Drive information:
Drive Version:
Boot Version:
Cube ID:
Drive Type:
U7 HEX Monitor
Hex Monitor
Table 2.5 Magnetek AC Drive Table
# Display Parameter Description Unit Range Defaults Factory
