Program 84 : Hardware Setup for VoIP
84-06 : VoIPU Setup
Aspila EX Software Manual Programming 1001
84-06 : VoIPU Setup
Description
Use Program 84-06 : VoIPU Setup to setup the details of VoIPU PCB.
Input Data
Conditions
None
Level:
Aspila EX
IN •Available.
SLOT Number 01-16
Item
No.
Item Input Data Default Description
01 RTP Port Number 0-65535 10020
02 RTCP Port Number RTP Port Number + 1 10021 It has to be RTP Port Number + 1.
03 H.245 Port Number 0-65535 10100
04 Fractlost threshold 0-4294967295 ms 0 The data will be sent to the NTCPU if the
value exceeds the defined value.
05 pktsLost threshold 0-4294967295 0 The data will be sent to the NTCPU if the
value exceeds the defined value.
06 Ext HighSeq threshold 0-4294967295 0 The data will be sent to the NTCPU if the
value exceeds the defined value.
07 jitter threshold 0-4294967295 sec 0 The data will be sent to the NTCPU if the
value exceeds the defined value.
08 lastSR threshold 0-4294967295 0 The data will be sent to the NTCPU if the
value exceeds the defined value.
09 delayLSR threshold 0-4294967295 0 The data will be sent to the NTCPU if the
value exceeds the defined value.
10 DTMF behavior 0 : DTMF Relay disabled
1 : In-Band DTMF relay,
do NOT report to Host
processor
2 : Out of Band DTMF
relay, do not pass tones as
voice
0
11 0-65535 4000
