Program 82 : Basic Hardware Setup for Extension
82-04 : SLIU Initial Data Setup
970 Programming Aspila EX Software Manual
82- 04 : SL IU In itia l Dat a Setu p
Description
Use Program 82-04 : SLIU Initial Data Setup to define the various basic timers for the ASTU
PCB.
Input Data
Conditions
None
Feature Cross Reference
None
Level:
Aspila EX
MF •Available.
Item No. Item Input Data Default
01 Companding method type 0- u-law
1- A-law
0 (u-law)
02 Ringing frequency 0- 25Hz
1- 20Hz
2- 16Hz
2 (16Hz)
03 Minimum break time 1-255 (5ms-1275ms) 2 (10ms)
04 Maximum break time 1-255 (5ms-1275ms) 20 (100ms)
05 Minimum make time 1-255 (5ms-1275ms) 2 (10ms)
06 Maximum make time 1-255 (5ms-1275ms) 20 (100ms)
07 Minimum hook flash time 1-255 (5ms-1275ms) 21 (105ms)
08 Maximum hook flash time 1-255 (5ms-1275ms) 200 (1000ms)
09 Minimum ground flash time 1-255 (5ms-1275ms) 21 (105ms)
10 Minimum off-hook time 1-255 (5ms-1275ms) 21 (105ms)
11 No detection time after off-hook 1-255 (5ms-1275ms) 60 (300ms)
12 No detection time after pulse dial detection 1-255 (5ms-1275ms) 70 (350ms)
13 Loop disconnect time, Reversal time 1-255 (10ms-2550ms) 60 (600ms)
14 Ring, Message wait period time 1-255 (5ms-1275ms) 150 (750ms)
