Feature Descriptions MDM6000 Satellite Modem
Parameter Value Description
Maximum power
step up 
dBm/100ms
Typically set this
value to
0.1dBm/100ms
This step up value defines how fast fading will be
compensated.
In other words, how much dBm (power) is added per
second by the controller during fading. (Refer to the figure
below.)
Note: If the step up value is too high, this
could cause overshoot which will violate
the PEB.
Typically set this value to 0.1dBm/100ms.
Maximum power
step down
dBm/100ms
Typically set this
value to
0.5dBm/100ms.
The step down value defines how fast the power decrease
is done. How much dBm is removed per second by the
controller.
This should be faster than the power step up.
Again to avoid violating the PEB. (Refer to the figure
below.)
Typically set this value to 0.5dBm/100ms.
The max power step down should be
larger than the max power step up.
