Appendix - Technical Specifications MDM6000 Satellite Modem
BAUD RATE RANGE
Modulator 0,050 - 72Mbaud
Class 1 Demodulator
(depending on MODCOD)
1 - 60Mbaud
Class 2 Demodulator 256kbaud - 72Mbaud
FRAME LENGTH
DVB-S2 Short Frames 16200 bits for DVB-S2, and
DVB-S2X
DVB-S2 Normal Frames 64800 bits for DVB-S2, DVB-S2X
and Newtec's S2 Extensions
CLEAN CHANNEL TECHNOLOGY
• Roll-off : 5% -10% -15% -20% - 25% - 35%;
• Optimum carrier spacing;
• Advanced filter technology.
AUTOMATED EQUALINK (TM) 2.0
• Non-linear pre-distortion for all ModCods.
CARRIER INTERFERENCE REDUCTION
• DVB RF Carrier ID (DVB-CID);
• Spread Spectrum Modulator (BPSK);
• Supports User Data;
• Compliant to DVB Standard.
