Appendix - Technical Specifications MDM6000 Satellite Modem
The Baseband frame header decoder will not work reliably below -2.0dB Es/No. When operating a
link below -2dB Es/No, occasional unlock events are expected due to BBheader decoder failures.
Although few modcods have lower threshold, ACM operation below -2dB is not recommended.
In pilots off mode the Baseband frames phase tracking is based on payload symbols. For a given
modulation the phase tracking is more difficult for low FEC rates and low symbol rates.
For optimal performance, a minimum symbol rate should be taken into account when working in
pilots OFF mode. Below that threshold pilots ON is strongly recommended. See the tables below for
minimum symbol rates.
DVB-S2 Pilots Off Performance:
ModCod
Min Symbol Rate (Mbaud)
QPSK 1/4
5
QPSK 1/3
1
QPSK 2/5
1
QPSK 1/2
0,256
QPSK 3/5
0,256
QPSK 2/3
0,256
QPSK 3/4
0,256
QPSK 4/5
0,256
QPSK 5/6
0,256
QPSK 8/9
0,256
8PSK 3/5
5
8PSK 2/3
1
8PSK 3/4
0.256
8PSK 5/6
0.256
8PSK 8/9
0.256
8PSK9/10 0.256
16APSK 2/3
5
16APSK 3/4
1
16APSK 4/5
0.256
16APSK 5/6
0.256
16APSK 8/9
0.256
16APSK 9/10
0.256
32APSK 3/4
0.256
32APSK 4/5
0.256
32APSK 5/6
0.256
32APSK 8/9
0.256
32APSK 9/10
0.256
