Appendix - Technical Specifications MDM6000 Satellite Modem
DVB-S2x Pilots Off Performance:
ModCod
Min Symbol Rate (Mbaud)
QPSK 13/45
2
QPSK 9/20
0.256
QPSK 11/20
0.256
8APSK 5/9-L
0.256
8APSK 26/45-L
0.256
8APSK 23/36
2
8APSK 25/36
0.256
16APSK 1/2-L
0.256
16APSK 8/15-L
0.256
16APSK 5/9-L
0.256
16APSK 26/45
20
16APSK 3/5
10
16APSK 3/5-L
0.256
16APSK 28/45
10
16APSK 23/36
5
16APSK 2/3-L
0.256
16APSK 25/36
2
16APSK 13/18
1
16APSK 7/9
0.256
16APSK 77/90
0.256
32APSK 2/3-L
2
32APSK 32/45
1
32APSK 11/15
0.256
32APSK 7/9
0.256
64APSK 32/45-L
0.256
64APSK 11/15
10
64APSK 7/9
0.256
64APSK 4/5
0.256
64APSK 5/6
0.256
128APSK 3/4 do not use
128APSK 7/9
36
256APSK 29/45-L
1
256APSK 2/3-L
1
256APSK 31/45-L
0.256
