46 Chapter 2 Use the Océ TDS700 to print a job
The printer operator panel
[7]
Nr Key types Function
1Key
operator
key
This key gives access to a number of printer related options.
■ Demo print
■ Print settings
■ Administrator only
■ Service only
2 Up / Down
key
This key situated to the right of the graphical display is used
to display the next or previous option from the selected menu
choice and to select the desired option. Use the top key to
move in upward direction through a list. Use the lower key to
move down a list.
3 Stop key The red stop key is used to stop the present print job. After this
key is pressed, a dialogue will be displayed asking for
confirmation.
Note: The printing process does not stop
immediately since a number of prints may already
have been submitted to the printer after
processing. The prints cannot be stopped.
4+5 Selection
keys
The selection keys are located immediately below the
graphical display.
■ The left key can be used to activate one of the main menu
choices (Language, Folding or Media) on the left part of
the display.
■ The right selection key can be used to activate the options
on the right part of the graphical display.
Note: A shadow highlighting effect is used to
indicate the active menu option.
Note: To identify the active selection, the dotted
line around this selection is changed into an
uninterrupted line and the small selection
triangles next to the specified option are no longer
dimmed. These selection triangles indicate that
you can select an option from a pre-defined list
with the help of the Up / down key.
6 On-line key Use the on-line key to put the printer on-line or off-line. If the
green light above the on-line key is on, the printer is on-line;
if this light is off, the printer is off-line.
