DMTA-10084-01EN, Rev. 2, November 2018
Chapter 9
134
— The Up Arrow ( ) button moves the selection to the cell above the
currently selected cell and changes the active file ID to that of the newly
selected cell.
— The Down Arrow ( ) button moves the selection to the cell below the
currently selected cell and changes the active file ID that of to the newly
selected cell.
To overwrite grid data in a live screen
1. Use the arrow buttons to navigate to the cell to overwrite.
2. Make a measurement.
3. Turn the adjustment knob to highlight Save, and press the Enter key.
A dialog box appears asking if you want to overwrite the ID.
4. Press the Enter key to overwrite the data.
To use a grid when viewing a saved file
1. On the Settings menu, select the File icon to open the File setup page.
2. Turn the adjustment knob to select the specific file that you want to work with,
and then press the Enter key.
3. Press the Tab key to highlight the Contents button.
4. Use the arrow buttons to navigate through the grid.
5. Press the Tab key to move to the Select ID button to highlight and select a specific
ID for viewing (see Figure 9-27 on page 135).
