Chapter 5 44
— Off
— On
• Brightness
Used to adjust the screen brightness by choosing one of the preset values (0 %,
25 %, 50 %, 75 %, or 100 %).
• Color Scheme
Sets the overall instrument color scheme.
— Default: default multi color display
— Classic: EPOCH 650 color scheme
— Outdoor (White): white background, black text
— Outdoor (Yellow): yellow background, black text
— Mono: Black background, white text
• Display Rotation
Controls whether the display changes orientation when the instrument is rotated
90, 180, or 270 degrees.
— Off
— On
• Pullout Persistence
Controls whether or not the Sidebar menu is always displayed in Inspection
mode.
— Off
— On
5.4.3 Measurement Setup Page
The Measurement Setup page (see Figure 5-9 on page 45) enables you to select which
measurement appears in the measurement reading boxes at the top of the software
live A-scan screen.
To open the Measurement Setup page
 Select the Meas Setup icon ( ) to open the Measurement Setup page (see
Figure 5-9 on page 45).
