DMTA-10084-01EN, Rev. 2, November 2018
Chapter 1
8
1.1 Shift Key
The Shift key ( ) is used to activate the second function, changing the way the
ESC, Enter, and Tab keys function.
1.2 ESC Key
The ESC key ( ) is used to move the focus to the previous menu in the user
interface (UI). The Shift ( ), ESC ( ) key sequence changes the display
mode ( ) of the UI.
1.3 Enter Key
The Enter key ( ) is used to accept a highlighted parameter (selected with the
adjustment knob). The Shift ( ), Enter ( ) key sequence switches between
coarse and fine adjustment ( ) of the highlighted parameter with the adjustment
knob.
1.4 Tab Key
The Tab key ( ) moves the focus to and selects the next element in the UI for an
action. In certain menus, the Tab key ( ) moves the focus to the next icon or
button. The Shift ( ), Tab ( ) key sequence immediately returns to the
live A-scan display from any level of menu, dialog box, or setup page.
