Olympus EPOCH 6LT - Figure 5-2 Settings Menu; Opening a Setup Page

DMTA-10084-01EN, Rev. 2, November 2018
Chapter 5 34
Figure 5-2 Settings menu
5.1 Opening a Setup Page
Opening a setup page requires opening and navigating through the setup menu, the
Settings menu, and then opening one of the Settings menu setup pages.
To open a setup page
1. On the live A-scan screen, press the Shift ( ), Escape ( ) key sequence
to access the setup menu.
2. Turn the adjustment knob to move to and highlight the Settings icon ( ).
3. Press Enter ( ) to open the Settings menu.
4. On the Settings menu, turn the adjustment knob to move to and highlight one of
the Settings icons.
