DMTA-10084-01EN, Rev. 2, November 2018
Pulser/Receiver Adjustments
67
— Manual is used to manually set the PRF value.
To adjust the PRF value with PRF Mode set to Manual
In the pulser dialog box, press the Tab key to select PRF, and then turn the
adjustment knob to change the PRF value.
The EPOCH 6LT is a single-shot instrument. This means that the instrument acquires,
measures, and draws the complete A-scan with each pulse rather than using multiple
acquisitions to construct a full waveform. The measurement rate in the EPOCH 6LT is
always equal to the PRF rate unless you are using a multiplexer.
6.3 Adjusting the Receiver
The receiver settings are accessed in the Receiver dialog box.
To select the receiver
1. On the setup menu, turn the adjustment knob to select the Receiver ().
2. Press the Enter key to display the receiver dialog box (see Figure 6-4 on page 68).
