Olympus EPOCH 6LT - File Management; Instrument Settings; User Keys Setup Page

DMTA-10084-01EN, Rev. 2, November 2018
Setup Pages 37
c) Turn the adjustment knob to select Delete ( ) on the virtual keypad,
then press Enter ( ) to delete the character.
4. To save the entered data and exit the setup page, press Tab ( ) until the
Apply or Create button is selected, and then press Enter ( ).
5.3 File Management Pages
See “Data Logger Setup Pages” on page 104.
5.4 Instrument Settings Pages
The Instrument Settings setup pages are used to set up the general hardware aspects
of the EPOCH 6LT.
5.4.1 User Keys Setup Page
Custom user keys affect the Inspection mode sidebar menu action that occurs when
the Home (Shift [ ], Tab [ ] key) sequence is pressed.
The default action when you press the Shift, Tab key sequence is that the live A-scan
(Home) screen is displayed (see Figure 5-4 on page 38).
