DMTA-10084-01EN, Rev. 2, November 2018
Setup Pages
45
Figure 5-9 Measurement Setup page
The available parameter selections are:
• Reading Selection
Sets the measurement reading box mode.
— Auto: Automatically makes the selection based on instrument function
— Manual: Readings correspond to the manually defined selections
• Reading1 to Reading5
Each measurement reading box is defined independently when in Manual mode.
Figure 5-10 on page 46 shows an example of the measurement reading boxes.
Each box displays an icon that indicates the type of measurement being displayed
and the measurement value.
Information
displayed in the
measurement
reading boxes
