DMTA-10084-01EN, Rev. 2, November 2018
Chapter 9
130
Restore permanently overwrites all existing data on the EPOCH 6LT with data from a
USB flash drive.
9.5 Grid View
Using the grid view enables you to observe the measurements saved in multiple IDs
of the active file displayed on the live A-scan display. This feature can be used for any
file or file type, but it is most often used when conducting a thickness survey using a
predefined inspection pattern. When used in a thickness survey, the grid view
provides a partial or full-screen grid of thickness measurements arranged by columns
and rows. When you save data to an ID in the file, the saved thickness reading
appears in the corresponding cell in the grid. The grid can also be color coded to
enable you to rapidly identify an area of critical thinning.
9.5.1 Activating the Grid View
The grid view must be activated before it is visible on the screen.
To activate the grid view
1. When on the live A-scan display, press Shift, Escape key sequence to display the
setup menu.
2. Turn the adjustment knob to scroll the Tools icon ( ).
3. Press the Enter key to open the submenu of icons, then turn the adjustment knob
to select the Grid icon ( ) icon.
4. Press the Enter key to open the Grid dialog box (see Figure 9-25 on page 131).
5. Press the Enter key, and then turn the adjustment know to set Grid Enable to On.
