DMTA-10084-01EN, Rev. 2, November 2018
Inspection Mode 29
To use the file identifier shortcut menu
1. While on the live A-scan screen, press Tab ( ) to highlight the file identifier
bar, outlining it in red (see Figure 4-5 on page 29).
Figure 4-5 Highlighted file identifier bar
2. Press Enter ( ) to open the shortcut menu.
3. Turn the adjustment knob to choose a menu item, and then press Enter ( )
to open the associated setup page.
For detailed information on the data logger setup pages, see “Data Logger Setup
Pages” on page 104.
4.2.2 Measurement Reading Shortcut Menu
The measurement reading shortcut menu contains buttons that open the
Measurement and Display setup pages (see Figure 4-6 on page 30).
