Setup Pages
49
•Units
Determines the unit of measurement.
—µs
—mm
—in.
• Thickness Resolution
Sets the displayed resolution of a thickness measurement.
—X
—X.X
—X.XX
— X.XXX
• Ascan Mode
Sets the A-scan mode.
—Composite
— 1% Max
— 2% Max
—1D Min
—2D Min
• Curve Connected to Zero
Creates a horizontal line connecting the left side of the A-scan to the first acquired
point when building a DAC curve.
—Off
—On
Gate1 Ref dB-Current Amp Comparison value in dB measuring the
difference between the gate 1 echo height
and the reference gain.
Gate2 Ref dB-Current Amp Comparison value in dB measuring the
difference between the gate 2 echo height
and the reference gain.
Table 3 Available measurement readings (continued)
Flag Measurement reading Description
