6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
6
Communication Function
226Fh
2nd Acceleration Time 2
A292
(HIGH)
R/W
1 to 360000 0.01 [s]
5-66
2270h
A292
(LOW)
R/W
2271h
2nd Deceleration Time 2
A293
(HIGH)
R/W
1 to 360000 0.01 [s]
2272h
A293
(LOW)
R/W
2273h
2-step Acceleration/
Deceleration Selection 2
A294 R/W
00: Switched via 2CH
terminal
01: Switched by setting
02: Enabled only when
switching forward/
reverse
−
2274h
2-step Acceleration
Frequency 2
A295
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
2275h
A295
(LOW)
R/W
2276h
2-step Deceleration
Frequency 2
A296
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
2277h
A296
(LOW)
R/W
2278h
to
230Bh
Not used −−Inaccessible −−
230Ch Electronic Thermal Level 2 b212 R/W 2000 to 10000 0.01 [%]
5-110
230Dh
Electronic Thermal
Characteristics Selection 2
b213 R/W
00: Reduced torque
characteristics
01: Constant torque
characteristics
02: Free setting
−
230Eh
to
2315h
Reserved −−− − −
2316h
Overload Limit 2
Selection
b221 R/W
00: Disabled
01: Enabled in acceleration/
constant speed
operation
02: Enabled in constant
speed operation
03: Enabled in acceleration/
constant speed
operation
(Accelerates during
regeneration)
−
5-114
2317h Overload Limit 2 Level b222 R/W 100 to 2000 0.1 [%]
2318h
Overload Limit 2
Parameter
b223 R/W 1 to 30000 0.1 [s]
2319h
to
2428h
Not used −−Inaccessible −−
2429h
Overload Warning Level 2 C241 R/W 0 to 2000 0.1 [%] 5-115
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
