Omron SYSDRIVE MX2 SERIES User Manual

6-72
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
6
Communication Function
242Ah
to
2501h
Not used −−Inaccessible −−
2502h Motor Parameter 2 H202 R/W
00: Standard motor
parameter
02: Auto-tuning data
−
5-145
2503h Motor Capacity 2 H203 R/W
00: 0.1
01: 0.2
02: 0.4
03: 0.55
04: 0.75
05: 1.1
06: 1.5
07: 2.2
08: 3.0
09: 3.7
10: 4.0
11: 5.5
−
2504h Motor Pole Number 2 H204 R/W
00: 2P
01: 4P
02: 6P
03: 8P
04: 10P
−
2505h
Speed Response 2
H205
(HIGH)
R/W
1 to 1000 1 [%]
2506h
H205
(LOW)
R/W
2507h Stabilization Parameter 2 H206 R/W 0 to 255 1 5-81
2508h
to
2515h
Reserved −−− − −
2516h Motor 2 Parameter R1
H220 R/W 1 to 65530 0.001 [ Ω ] 5-145
2517h Reserved −−− − −
2518h Motor 2 Parameter R2
H221 R/W 1 to 65530 0.001 [ Ω ] 5-145
2519h Reserved −−− − −
251Ah Motor 2 Parameter L
H222 R/W 1 to 65530 0.01 [mH] 5-145
251Bh Reserved −−− − −
251Ch Motor 2 Parameter Io H223 R/W 1 to 65530 0.01 [A] 5-145
251Dh
Motor 2 Parameter J
H224
(HIGH)
R/W
1 to 9999000 0.01 5-145
251Eh
H224
(LOW)
R/W
251Fh
to
2524h
Reserved −−− − −
2525h
Motor 2 Parameter R1
(Auto-tuning Data)
H230 R/W 1 to 65530 0.001 [ Ω ] 5-145
2526h Reserved −−− − −
2527h
Motor 2 Parameter R2
(Auto-tuning Data)
H231 R/W 1 to 65530 0.001 [ Ω ] 5-145
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
