Omron SYSDRIVE MX2 SERIES User Manual

9-23
9-3 Options
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
9
Specifications
Specifications
Power
supply
Model Inverter model
Rated input current
In (A) at an ambient
temperature of 50
° C
Power
loss (W)
Leakage current
(mA/phase) at 60 Hz
3-phase
200 VAC
3G3AX-NFI21 3G3MX2-A2001 3 × 6 A 3 < 1.5 (250 V)
3G3AX-NFI21 3G3MX2-A2002 3 × 6 A 3 < 1.5 (250 V)
3G3AX-NFI21 3G3MX2-A2004 3 × 6 A 3 < 1.5 (250 V)
3G3AX-NFI22 3G3MX2-A2007 3 × 10 A 4 < 1.5 (250 V)
3G3AX-NFI23 3G3MX2-A2015 3 × 20 A 6 < 1.5 (250 V)
3G3AX-NFI23 3G3MX2-A2022 3 × 20 A 6 < 1.5 (250 V)
3G3AX-NFI24 3G3MX2-A2037 3 × 30 A 9 < 1.5 (250 V)
3G3AX-NFI25 3G3MX2-A2055 3 × 40 A 12 < 1.5 (250 V)
3G3AX-NFI26 3G3MX2-A2075 3 × 60 A 17 < 1.5 (250 V)
3G3AX-NFI27 3G3MX2-A2110 3 × 80 A 21 < 1.5 (250 V)
3G3AX-NFI28 3G3MX2-A2150 3 × 100 A 23 < 1.5 (250 V)
1-phase
200 VAC
3G3AX-NFI21 3G3MX2-AB001 3 × 6 A 3 < 1.5 (250 V)
3G3AX-NFI21 3G3MX2-AB002 3 × 6 A 3 < 1.5 (250 V)
3G3AX-NFI22 3G3MX2-AB004 3 × 10 A 4 < 1.5 (250 V)
3G3AX-NFI23 3G3MX2-AB007 3 × 20 A 6 < 1.5 (250 V)
3G3AX-NFI24
3G3AX-NFI23
*1
*1. With the 3G3AX-NFI23, only the CT rating is supported.
3G3MX2-AB015 3 × 30 A
3 × 20 A
9
6
< 1.5 (250 V)
3G3AX-NFI24 3G3MX2-AB022 3 × 30 A 9 < 1.5 (250 V)
3-phase
400 VAC
3G3AX-NFI41 3G3MX2-A4004 3 × 7 A 2 < 7.5 (480 V)
3G3AX-NFI41 3G3MX2-A4007 3 × 7 A 2 < 7.5 (480 V)
3G3AX-NFI41 3G3MX2-A4015 3 × 7 A 2 < 7.5 (480 V)
3G3AX-NFI42 3G3MX2-A4022 3 × 10 A 4 < 7.5 (480 V)
3G3AX-NFI42 3G3MX2-A4030 3 × 10 A 4 < 7.5 (480 V)
3G3AX-NFI43 3G3MX2-A4040 3 × 20 A 6 < 7.5 (480 V)
3G3AX-NFI43 3G3MX2-A4055 3 × 20 A 6 < 7.5 (480 V)
3G3AX-NFI44 3G3MX2-A4075 3 × 30 A 9 < 7.5 (480 V)
3G3AX-NFI45 3G3MX2-A4110 3 × 40 A 12 < 7.5 (480 V)
3G3AX-NFI46 3G3MX2-A4150 3 × 50 A 15 < 7.5 (480 V)
