Omron SYSDRIVE MX2 SERIES User Manual

Appendix-14
Appendix-4 Notes on Compliance with EC Directives and UL/cUL Standards
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
A
Appendix
Notes on UL/cUL Standards
UL Cautions
The warnings and instructions in this section summarizes the procedures necessary to ensure
an inverter installation complies with Underwriters Laboratories guidelines.
 Use 60/75°C Cu wire only.
(For models: 3G3MX2-A2001, -A2002, -A2004, -A2007, -AB015, -AB022, -A4004, -A4007,
-A4015, -A4022 and -A4030)
 Use 75°C Cu wire only.
(For models: 3G3MX2-AB001, -AB002, -AB004, -AB007, -A2015, -A2022, -A2037, -A2055,
-A2075, -A2110, -A2150, -A4040, -A4055, -A4075, -A4110 and -A4150)
 Suitable for use on a circuit capable of delivering not more than 100,000 rms Symmetrical
Amperes, 240 or 480 Volts Maximum.
 When Protected by CC, G, J, or R Class Fuses, or when Protected By A Circuit Breaker Having
An Interrupting Rating Not Less Than 100,000 rms Symmetrical Amperes, 240 or 480 Volts
Maximum.
 Install device in pollution degree 2 environment.
 Maximum surrounding air temperature rating of 50°C.
 Solid State motor overload protection reacts with max. 150% of FLA.
 Integral solid state short circuit protection does not provide branch circuit protection. Branch circuit
protection must be provided in accordance with the National Electric Code and any additional
local codes.
Fuse Size
The Inverter shall be connected with a UL Listed Cartridge Nonrenewable fuse, rated 600Vac
with the current ratings as shown in the table below.
Model No. Type Rating
3G3MX2-AB001, 3G3MX2-AB002, 3G3MX2-AB004 Class J 10 A, AIC 200 kA
3G3MX2-AB007 15A, AIC 200 kA
3G3MX2-AB015 20A, AIC 200 kA
3G3MX2-AB022 30A, AIC 200 kA
3G3MX2-A2001, 3G3MX2-A2002, 3G3MX2-A2004 10 A, AIC 200 kA
3G3MX2-A2007, 3G3MX2-A2015 15A, AIC 200 kA
3G3MX2-A2022 20A, AIC 200 kA
3G3MX2-A2037, 3G3MX2-A2055 30A, AIC 200 kA
3G3MX2-A2075 40A, AIC 200 kA
3G3MX2-A2110 60A, AIC 200 kA
3G3MX2-A2150 80A, AIC 200 kA
3G3MX2-A4004, 3G3MX2-A4007, 3G3MX2-A4015, 3G3MX2-A4022 10 A, AIC 200 kA
3G3MX2-A4030, 3G3MX2-A4040, 3G3MX2-A4055 15A, AIC 200 kA
3G3MX2-A4075 20A, AIC 200 kA
3G3MX2-A4110 30A, AIC 200 kA
3G3MX2-A4150 40A, AIC 200 kA
