Omron SYSDRIVE MX2 SERIES User Manual

Appendix-15
Appendix-4 Notes on Compliance with EC Directives and UL/cUL Standards
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
A
Appendix
Terminal Symbols and Screw Size
Model No.
Screw
Size
Required
Torque(N•m)
Wire Range
3G3MX2-AB001, 3G3MX2-AB002, 3G3MX2-AB004
M3.5 1.0 AWG16 (1.3mm
2
)
3G3MX2-AB007
M4 1.4 AWG12 (3.3mm
2
)
3G3MX2-AB015, 3G3MX2-AB022
M4 1.4 AWG10 (5.3mm
2
)
3G3MX2-A2001, 3G3MX2-A2002, 3G3MX2-A2004,
3G3MX2-A2007
M3.5 1.0 AWG16 (1.3mm
2
)
3G3MX2-A2015
M4 1.4 AWG14 (2.1mm
2
)
3G3MX2-A2022
M4 1.4 AWG12 (3.3mm
2
)
3G3MX2-A2037
M4 1.4 AWG10 (5.3mm
2
)
3G3MX2-A2055, 3G3MX2-A2075
M5 3.0 AWG6 (13mm
2
)
3G3MX2-A2110
M6 3.9 to 5.1 AWG4 (21mm
2
)
3G3MX2-A2150
M8 5.9 to 8.8 AWG2 (34mm
2
)
3G3MX2-A4004, 3G3MX2-A4007, 3G3MX2-A4015
M4 1.4 AWG16 (1.3mm
2
)
3G3MX2-A4022, 3G3MX2-A4030,
M4 1.4 AWG14 (2.1mm
2
)
3G3MX2-A4040
M4 1.4 AWG12 (3.3mm
2
)
3G3MX2-A4055, 3G3MX2-A4075
M5 3.0 AWG10 (5.3mm
2
)
3G3MX2-A4110, 3G3MX2-A4150
M6 3.9 to 5.1 AWG6 (13mm
2
)
