4-2 Function Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
4
Parameter List
External DC injection braking
A058
Startup Internal
DC Injection
Braking Time
0.0 to 60.0 0.0 no yes s
5-135
A059
DC Injection
Braking Carrier
Frequency
2.0 to 15.0/10.0
(heavy load/light load)
5.0/2.0 no yes
kHz
Limit/jump
A061
Frequency
Upper Limit 1
0.00
Frequency Lower Limit 1 to
Maximum Frequency 1
0.00 no yes Hz
5-60
A261
Frequency
Upper Limit 2
0.00
Frequency Lower Limit 2 to
Maximum Frequency 2
0.00 no yes Hz
A062
Frequency
Lower Limit 1
0.00
Starting Frequency to
Frequency Upper Limit 1
0.00 no yes Hz
A262
Frequency
Lower Limit 2
0.00
Starting Frequency to
Frequency Upper Limit 2
0.00 no yes Hz
A063
Jump
Frequency 1
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
5-61
A064
Jump
Frequency
Width 1
0.00 to 10.00(100.0) 0.50 no yes Hz
A065
Jump
Frequency 2
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
A066
Jump
Frequency
Width 2
0.00 to 10.00 (100.0) 0.50 no yes Hz
A067
Jump
Frequency 3
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
A068
Jump
Frequency
Width 3
0.00 to 10.00 (100.0) 0.50 no yes Hz
Others
A069
Acceleration
Stop Frequency
0.00 to 99.99
100.0 to 400.0 (1000.)
0.00 no yes Hz
5-62
A070
Acceleration
Stop Time
0.0 to 60.0 0.0 no yes s
Parameter No. Function name Monitor or data range
Default
setting
Set data
Data can
be set
during
RUN
Data can be
changed
during RUN
Unit Page
