Oracle X7-2 Service Manual

Identify and Remove a Faulty Processor
■
If the processor fault LED is off, then the processor is operating properly.
■
If the processor fault LED is on (amber), then the processor is faulty and must be replaced.
Callout Description
1 Fault Remind button
2 Fault Remind LED
3 Processor 0 fault LED
4 Processor 1 fault LED
Servicing Processors (FRU) 139

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
