16.10.3 Cam Pattern Editing Execution Area
●: Available, -: Not available
Axis no.
Unit
memory
no. (Hex)
Name Default Description R W
- UM 66F98
Cam pattern
reading result
H0
Stores the result of reading processing
(response code).
H0: Normal end
Other than H0: Abnormal end

-
- UM 66F99
Cam pattern
rewriting result
H0
Stores the result of rewriting processing
(response code).
H0: Normal end
Other than H0: Abnormal end

-
(Note): In the case of abnormal end, the codes in the following table are stored.
Code Name Description
Object
Countermeasures
R
W
H FF01
Cam pattern number
setting error
Cam pattern no. The
setting value is out of the
range.
 
Check the set value of the cam
pattern number.
H FF02
Number of cam
pattern setting
sections setting error
The set number of cam
pattern setting sections is
out of the settable range.
-

Check the set number of setting
sections.
H FF03
Shift amount setting
error
The set shift amount is out
of the settable range.
-

Check the set value of the shift
amount.
H FF05
Start phase setting
error 1
The set start phase is out
of the settable range.
-

Check the set value of the start
phase in each section.
H FF06
Start phase setting
error 2
The set start phase is the
same as or smaller than
the start phase of the
previous section.
-

Check if the relation between
the start phases of each section
is (Start phase of section n-1) <
(Start phase of section n).
H FF07
Start phase setting
error 3
The set start phase of the
section 1 is not 0.
-

Always set the start phase of
the section 1 to 0.
H FF0A
Displacement setting
error
The set value of the
displacement is out of the
settable range.
-

Check the set value of the
phase in each section.
H FF0B
Cam curve number
setting error
The set cam curve
number is out of the
settable range.
-

Check the set value of the cam
curve number in each section.
H FF10
Cam pattern reading
not executable error 1
An axis in synchronous
operation exists.

-
Cancel the synchronous
operation and execute the
reading.
H FF11
Cam pattern reading
not executable error 2
An operating axis exists.

-
Execute the reading when no
operating axis exists.
H FF20
Cam pattern rewriting
not executable error 1
An axis in synchronous
operation exists.
-

Cancel the synchronous
operation and execute the
rewriting.
H FF21
Cam pattern rewriting
not executable error 2
An operating axis exists. -

Execute the rewriting when no
operating axis exists.
H FF22
Cam pattern rewriting
not executable error 3
The reading request and
rewriting request turned
on simultaneously.
-

Check if the reading request
and rewriting request do not
turn on simultaneously. When
the reading request and writing
request turn on simultaneously,
the reading request takes
priority.
