8.23
TRANSMISSION
8
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
9. Apply a continuous b ead o f Crankcase 3 Bo nd
Sealant (PN 2871557) to the left hand transmission
mating surface.
10. Install the tra nsmission ca se cover an d r etaining
bolts
. Torque bolts to specification.
11. Install new seals into the transmission case halves.
• The snorkel shaf t se al ( F), sho uld be pr essed in
un
til it seats against the housing counter-bore.
• The input shaft seal (G), should be pressed in until
it
seats flush with the housing.
• The r ear ou tput sh aft se als (H), ca n be inst alled
using
a st andard b ushing inst allation too l. Se als
should b e inst alled j ust p ast the case lea d-in
chamfer (.070 in. or 1.8 mm from the outer face of
the bore).
12. Thoroughly clean the shift shaft housing. Be sure the
transmissi
on is in High gear prior to reassembly.
Transmission Case Bolts:
15-20 ft. lbs. (20-27 Nm)
