20. Using a 5 mm Allen wrench, remove the screws that
secure the pin ion shaft assembly (V). Lift the pin ion
shaft assembly stra ight up to r emove it fro m the
housing. Note the longer screw ( W) th at locks the
snorkel tube.
21. Remove all seals from the gearcase halves and clean
the
cases in preparation for assembly.
Gear Cluster Disassembly
22. Remove the b earing from the r everse shaft using a
b
earing puller. Remove the retaining ring and slide the
washers, 53T gear and needle bearing off the reverse
shaft (see Figure 8-1).
23. Remove the retaining ring and engagement dog from
th
e reverse shaft (see Figure 8-1).
24. Remove the retaining ring, washer, needle bearing,
an
d sprocket from the reverse shaft (see Figure 8-1).
25. Tilt the two shafts towards each other and remove the
sile
nt chain from the two shafts.
V
W
Figure 8-1
