Mixer : 3D Panning Control Bus Window
10 - 267
Speaker Coords Origin : Determines the base point in space for the XYZ coordinate settings. The drop-
down offers the choice of: <Room center> or any of the speakers present in the
room (by number). Speaker position is either relative to the center of the room, or
to the selected reference Speaker.
Display Coords: When checked the coordinates fro the selected speaker are shown numerically
and by a dotted orange line from the point of origin.Predefined Speaker
Arrangements/Channel Assignments
52 Predefined Room types listed below:
Mono 9.0 Surround
Stereo 9.1 Surround
3.0 Front 11.0 Surround
3.1 Front 11.1 Surround
3.0 Surround 5.0 Dolby
3.1 Surround 5.1 Dolby
4.0 Quadro 7.0 Dolby
4.1 Quadro 7.1 Dolby
4.0 Surround 9.0 Dolby
4.1 Surround 9.1 Dolby (Atmos)
5.0 Side (THX) 7.0 DTS (Neo:X)
5.1 Side (THX) 7.1 DTS (Neo:X)
5.0 Surround (SACD) 9.0 DTS (Neo:X)
5.1 Surround (SACD) 9.1 DTS (Neo:X)
6.0 Side 11.0 DTS (Neo:X)
6.1 Side 11.1 DTS (Neo:X)
6.0 Surround 10.2 TMH
6.1 Surround 12.2 TMH
7.0 Side 8.0 Auro
7.1 Side 9.1 Auro
7.0 Surround (SDDS) 10.1 Auro
7.1 Surround (SDDS) 11.1 (7+4) Auro
7.0 Surround (THX) 11.1 Auro
7.1 Surround (THX) 13.1 Auro
8.0 Surround 22.2 Hamasaki/NHK
8.1 Surround 30.2 La Totale
