Remote Control : Control by External Device
24 - 582
Note: These filter settings are mainly relevant where multiple controllers are in use. E.g. where a
Mixing console controls monitoring and recording.
Edit On/Off Frame Alignment and Delay
Edit On and Edit Off boxes enable delays (in ms) to be entered.
Note: 0 = Immediate Punch, 1 = Align to next Frame boundary, 2 or more = Align to the given
following Frame boundary.
Edit Preset (Track Arming) Mapping
The Map Track # combo box allows you to select a Track between 1 and 96 to be mapped to a choice made in the
second combo box from:
• Default
•No change
•Always Off
•Always On
or any Track between 1 and 96
This function is useful if more than one Pyramix is to be controlled by the same controller. E.g. with two machines
set up to record 32 Tracks each, Pyramix one is mapped 1 - 1 to 32 - 32 and Pyramix two is mapped 1 - 33 to 32 -
64
