Parameter Descriptions 2-81
7000-TD002A-EN-P – September 2007
Motor Protection Fault Class [Motor Prot Class]
Linear Number: 443
Default Value: Class2 Fault
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the class of the motor protective device. This is usually a protective relay on the
motor. The following options are available:
Disable This disables the fault input.
Class1 Fault The drive will shut down immediately
Class2 Fault The drive will perform a controlled shut down
Warning The drive will not shut down but a warning will be displayed
Input Protection 2 Fault Class [InputProt2 Class]
Linear Number: 444
Default Value: Class2 Fault
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the class of the second of the possible protective devices installed to provide
line protection. This is usually an overload or protective relay on the input isolation transformer or line
reactor, or from a source further upstream. The following options are available:
Disable This disables the fault input.
Class1 Fault The drive will shut down immediately
Class2 Fault The drive will perform a controlled shut down
Warning The drive will not shut down but a warning will be displayed
Auxiliary Protection Class [Aux Prot Class]
Linear Number: 445
Default Value: Class2 Fault
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the class of any other protective device that is used in the drive system. This
essentially is a spare input for any customer-specific protective device. The following options are
available:
Disable This disables the fault input.
Class1 Fault The drive will shut down immediately
Class2 Fault The drive will perform a controlled shut down
Warning The drive will not shut down but a warning will be displayed
