2-10 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Bus Transient Level [BusTransient Lvl]
Linear Number: 767
Minimum Value: 0.000 pu
Maximum Value: 32.767 pu
Access Level: Service
Read/Write: Read Only
The bus transient algorithm has been improved to reduce self-induced nuisance trips caused by fast dc
current, pulse number and firing angle changes. The rectifier temporarily disables the bus transient when
it determines that it may generate a transient in the input filter. This can be compared to Bus Tran Trip
#684 to determine when the transient occurs.
Diagnostics Parameters
Logic Command [Logic Command]
Linear Number: 257
Access Level: Monitor
Read/Write: Read Only
This parameter specifies the logic command used by the drive control. Refer to Appendix A for detailed
implementation. The following commands are displayed, with a one representing an active command:
Bit Enum Text Description
0 Not Stop Drive is ready to Run
1 Start Start the Drive
2 Jog Start the drive in Jog mode
3 Clr Flt Que Clear the Fault queue
4 Clr Warn Que Clear the Warning queue
5 Drive Reset Reset the drive
6 Direction Direction of rotation
7 Start Profle Drive Start profile
8 Stop Profle Drive Stop profile
9 Flash Mode DPI Adapter in Flash Mode
10 Unused
11 Synch Synchronous transfer to Bypass from Drive
12 De-Synch Synchronous transfer to Drive from Bypass
13 Force Stop Force Stop the drive (DPI)
14 Force Fault Force Fault the drive (DPI)
15 Unused
