Parameter Descriptions 2-157
7000-TD002A-EN-P – September 2007
Standard XIO Configurable Output 2 [StndXIO Config2]
Linear Number: 458
Default Value: Jog
Access Level: Advanced
Read/Write: Read/Write
This parameter allows the user to select/configure output 2 on the XIO board from a list of 28 available
options. The list is as follows:
Internal
Value
Enum Text Description
0 Unassigned The output is unassigned.
1 Reverse Drive is running in Reverse direction.
2 Drv Stopping Drive is Stopping
3 Auto Restart Drive is in Auto Restart mode.
4 Drv Overload Drive is running in an overload condition
5 Mtr Overload Motor is running in an overload condition
6 Thermal Alrm Drive has issued an alarm pertaining to its thermal performance
e.g. Loss of converter air flow in air cooled drives or loss of coolant
level in liquid cool drives.
7 Line Loss Loss of line input voltage
8 CtrlPwr Loss Loss of 120V AC Control Power
9 Test Mode Drive is in Test Mode
10 At Speed Drive is at commanded Speed
11 Sync Xfer Synchronous transfer is enabled
12 On Bypass Drive is running on Bypass
13 In Trq Limit Drive is in Torque Limit
14 Drive Accel Drive is accelerating
15 Drive Decel Drive is decelerating
16 Jog Drive is in Jog Mode
17 Remote Drive is in Remote Mode
18 IsoFan1Ctctr Turn Cooling Fan 1 in the Isolation Transformer cabinet
19 IsoFan2Ctctr Turn Cooling Fan 2 in the Isolation Transformer cabinet
20 Field Enable Field Current regulator is enabled (Synchronous motor only)
21 Field Start Start command to the field regulator (Synchronous motor only)
22 Spd Cmd Loss Speed Command Loss
23 Custom 1 Custom 1 Output
24 Custom 2 Custom 2 Output
25 Custom 3 Custom 3 Output
26 Custom 4 Custom 4 Output
27 Custom 5 Custom 5 Output
Contact Factory for availability
