2-40 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Hall Effect Current Sensor Burden for Neutral Current [HECS Brden RNeut]
Linear Number: 197
Default Value: 50.0 ohms
Minimum Value: 1.0 ohms
Maximum Value: 100.0 ohms
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the value of the burden resistor to measure the current in the neutral resistor
(Direct-to-Drive only). This parameter is reserved for future use only.
Contact factory for availability
Hardware Options 1 [HardwareOptions1]
Linear Number: 141
Default Value: 0000000010000000
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter allows user to select additional hardware options. A ‘1’ indicates that the option is
installed in the drive.
Bit Enum Text Description
0 Redn ConvFan Redundant converter cooling fan for Air cooled drives
1 RednIsoTxFan Redundant cooling fan for drives with integral Isolation Transformer
2 Redn PwrSup Redundant AC/DC power supply.
3 Output IsoTx Output Isolation Transformer
4 Input IsoSw Input Isolation Switch
5 Output IsoSw Output Isolation Switch
6 Bypass IsoSw Bypass Isolation Switch
7 DCNeutralVSB Voltage Sensing Board for DC/Neutral voltage measurement
8 Output Ctctr Output Contactor installed in the drive
9 Bypass Ctctr Bypass Contactor installed in the drive
10 Ambient Temp Ambient temperature measurement enabled
11 Rec ChB Temp Rectifier Channel B temperature
12 Redn Dvc Inv Redundant Inverter Device
13 Redn Dvc Rec Redundant Rectifier Device
14 Rockwell UPS Rockwell specified UPS installed in the drive
15 Customer UPS Customer supplied UPS installed in the drive
Contact factory for availability
