Parameter Descriptions 2-13
7000-TD002A-EN-P – September 2007
Drive Status Flag 2 [DrvStatus Flag2]
Linear Number: 238
Access Level: Service
Read/Write: Read Only
This parameter specifies the drive status flag and is used by drive control to make logical decisions. A ‘1’
represents an indicated status. The following states are displayed:
Bit Enum Text Description
0 Jog Drive is in Jog mode.
1 Local Drive is in Local Control Mode.
2 Class1 Fault Drive has tripped on a Class 1 Fault.
3 Class2 Fault Drive has tripped on a Class 2 Fault.
4 Run Req Drive start command has been issued.
5 Restart Req Drive will restart automatically following a line loss.
6 Gating Enble Line and machine converter devices are gating.
7 Drive Init Drive Initialization routines have been completed.
8 Gate Test Drive is in Gate Test mode.
9 Shrt Cct Tst Drive is in DC Current Test mode.
10 System Tst Drive is in System Test mode.
11 Open Cct Tst Drive is in Open Circuit Test mode.
12 Param Loaded Drive Parameters have been loaded.
13 Inv Init Inverter side initialization routines have been completed.
14 StaFlg2Bit14 Not Used bit
15 Conv Fan2 On Optional redundant converter cooling fan (Fan 2) has been switched on
Contactor Command [Contactor Cmd]
Linear Number: 505
Access Level: Service
Read/Write: Read Only
This parameter displays the command to close the various contactors configured with the drive (input,
output, and bypass). The contactors are specified by the parameter Hardware Options1 (141). A ‘1’
indicates that the contactor is being commanded by the drive to close.
Bit Enum Text Description
0 Input Ctctr Close Input contactor
1 Output Ctctr Close Output contactor
2 Bypass Ctctr Close Bypass contactor
3 Not Used
4
Not Used
5
Not Used
6
Not Used
7
Not Used
