Rockwell Automation PowerFlex 7000 Technical Data

2-176 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Port Logic Mask [Port Logic Mask]
Linear Number: 709
Default Value: 0000000001111111
Access Level: Advanced
Read/Write: Read/Write
The parameter is used to configure the value of the Logic Mask Active attribute unless the “Advanced” bit
is set in the attribute. If the “Advanced” bit is already set in the Logic Mask Active attribute, the value last
written to the attribute is used until a new value is written directly to the attribute. If the bit for a port is set
to “0”, the port will have no control functions of the drive except for stop.
Bit Enum Text Description
0 Host
1 DPI Port1
2 DPI Port2
3 DPI Port3
4 DPI Port4
5 DPI Port5
6 DPI Port6
7 Reserved Programming Terminal I/O
8 Reserved
9 Reserved
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
Logic Mask Act [Logic Mask Act]
Linear Number: 710
Access Level: Advanced
Read/Write: Read Only
This parameter provides read-only access to the current value of the Logic Mask Active attribute for
diagnostic purposes. When bit 15 is set, it indicates that FactoryTalk Security or some other Advanced
Security tool has set the Logic Mask Active attribute. If the bit for a port is set to “0”, the port will have no
control functions of the drive except for stop.
Bit Enum Text Description
0 Host
1 DPI Port1
2 DPI Port2
3 DPI Port3
4 DPI Port4
5 DPI Port5
6 DPI Port6
7 Reserved
8 Reserved
9 Reserved
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Advanced
