2-90 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Motor Fault Mask 1 [Mtr Fault1 Mask]
Linear Number: 561
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
his parameter specifies the mask for the first fault word corresponding to motor protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
Mtr OvrCur Motor Over current Fault
Mtr OvrVolt Motor Overvoltage Fault
MtrNeuOvrVol Motor Neutral Over Voltage Fault
Mtr FlxUnbal Motor Flux Unbalance Fault
Mtr CurUnbal Motor Current Unbalance Fault
Mtr OvrLoad Motor Overload Fault
Mtr OvrSpeed Motor Over Speed Fault
Mtr Stall Motor Stall Fault
Mtr LoadLoss Motor Load Loss Fault
SynFieldLoss Synchronous Field Loss Fault 
MtrSlipRange Motor Slip Out of Range Fault
Unused
Unused
Unused
Unused
Unused
 Contact factory for availability
Drive Warning Mask 1 [Drv Wrn1 Mask]
Linear Number: 397
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
his parameter specifies the mask for the first warning word corresponding to drive protection. A ‘1’
represents an enabled warning; a ‘0’ represents a disabled warning. The bit assignment is:
Bit Enum Text Description
0 Drv OvrLoad Drive Overload warning
1 Mstr UndVolt Master Bridge Under Voltage warning
2 Slv1 UndVolt Slave1 Bridge Under Voltage warning
3 Slv2 UndVolt Slave2 Bridge Under Voltage warning
4 DCLnk OvrCur DC Link Over Current warning
5 Rec OvrVolt Rectifier Over Voltage Fault
6 Line Synch Loss of line synchronization
7 InpCtctr Fbk Drive Input Contactor Feedback Status Loss with MV present
8 Unused
9 Line Loss Loss of medium voltage or loss of medium voltage frequency
10 RecHSnkOvTmp Rectifier Heatsink Over Temperature warning
11 RecChB OvTmp Rectifier Channel B Over Temperature warning
12 BusTransient Bus Transient warning
13 LineCapRange Line Filter Capacitor pu value outside normal range
14 RAM Batt Low RAM Battery Low
15 DCLink Range DC Link pu value outside normal range
