Rockwell Automation PowerFlex 7000

Parameter Descriptions 2-89
7000-TD002A-EN-P – September 2007
Drive Fault Mask 5 [Drv Fault5 Mask]
Linear Number: 563
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the fifth fault word corresponding to drive protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
0 Conv AirFlow Converter Air Flow Pressure Value Fault
1 IsoTxAirFlow Isolation Transformer Air Flow Pressure Value Fault
2 InvHSnkOvTmp Inverter Heatsink Over Temperature fault
3 InvHSnkLoTmp Inverter Heatsink Low Temperature fault
4 InvHSnkFbrOp Inverter Heatsink Fiber Optic Cable Fault
5 InvHSnk Sens Inverter Heatsink Sensor Fault
6 Amb OvTmp Ambient Over Temperature Fault
7 Amb LoTmp Ambient Low Temperature Fault
8 Amb FbrOp Ambient Fiber Optic Cable Fault
9 Amb Sens Ambient Temperature Sensor Fault
10 InvAnaSlfTst Inverter Self Analog Test Fault
11 InvFbrOptCfg Inverter Fiber Optic Configuration Fault
12 Unused
13 Inv A2D Conv Inverter Analog to Digital Converter Fault
14 RecHeartbeat Rectifier Heartbeat Fault
15 Idc HECS Con DC Current HECS Connector Fault
Drive Fault Mask 6 [Drv Fault6 Mask]
Linear Number: 8
Default Value: 1111111111111111
Access Level: Service
Read/Write: Read/Write
This parameter specifies the mask for the sixth fault word corresponding to drive protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
0 DAN Comm Drive Area Network Communication Fault – Parallel Drive Application
1 Mstr Xfr Err Master Transfer Error– Parallel Drive Application
2 PDCapcityLow Parallel Drive capacity is low– Parallel Drive Application
3 Main VSB Main Voltage Sensing Board has not been plugged in to ACB
4 Sync VSB Bypass Voltage Sensing Board has not been plugged in to ACB
5 DC Neut VSB DC and Neutral Sensing Board has not been plugged in to ACB
6 InpLock5min Input contactor is locked out for 5 minute (line over current)
7 InpLockIndef Input contactor is locked out indefinitely (line over current and PLL
error)
8 ProcVarLossF Process Variable from the customer process sensor is lost
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
