2-88 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Drive Fault Mask 3 [Drv Fault3 Mask]
Linear Number: 396
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the third fault word corresponding to drive protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
0 Drv OvrLoad Drive Overload Fault
1 RNeutOvrLoad Line Neutral to Ground Overvoltage Fault
2 RecHSnkOvTmp Rectifier Heatsink Over Temperature Fault
3 RecHSnkLoTmp Rectifier Heatsink Low Temperature Fault
4 RecHSnkFbrOp Rectifier Heatsink Fiber Optic Cable Loss Fault
5 RecHSnk Sens Rectifier Heatsink Sensor Loss Fault
6 RecChB OvTmp Rectifier Channel B Over Temperature Fault
7 RecChB LoTmp Rectifier Channel B Low Temperature Fault
8 RecChB FbrOp Rectifier Heatsink Channel B Fiber Optic Cable disconnected Fault
9 RecChB Sens Rectifier Channel B Sensor Loss Fault
10 Dvc AK/Snubb Device anode-Cathode or Snubber Fault
11 Current Sens Current Sensor Fault
12 Unused
13 Unused
14 Unused
15 Unused
Drive Fault Mask 4 [Drv Fault4 Mask]
Linear Number: 562
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the fourth fault word corresponding to drive protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
0 Inv OvrVolt Inverter Over Voltage Fault
1 Drv Out Open Drive Output Contactor Open Fault
2 SyncXferFail Synchronous Transfer Failed
3 Tach Loss Tachometer Loss Fault
4 MV Sys Test Medium Voltage applied to drive in System Test Fault
5 MV Gate Test Medium Voltage applied to drive in Gating Test Fault
6 InpCtctrOpen Input Contactor Open Fault
7 OutCtctrOpen Output Contactor Open Fault
8 BypCtctrOpen Bypass Contactor Open Fault
9 No Out Ctctr No Output Contactor Fault
10 Inp IsoOpen Input Isolation Switch Open Fault
11 Out IsoOpen Output Isolation Switch Open Fault
12 Byp IsoOpen Bypass Isolation Switch Open Fault
13 Inp IsoClsd Input Isolation Switch Closed Fault
14 Out IsoClsd Output Isolation Switch Closed Fault
15 Byp IsoClsd Bypass Isolation Switch Closed Fault
