Parameter Descriptions 2-93
7000-TD002A-EN-P – September 2007
Motor Warning Mask 1 [Mtr Wrn1 Mask]
Linear Number: 565
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the first warning word corresponding to motor protection. A ‘1’
represents an enabled warning; a ‘0’ represents a disabled warning. The bit assignment is:
Bit Enum Text Description
0 Mtr OvrLoad Motor Overload warning
1 Mtr CapRange Motor Filter Capacitor pu value outside normal range
2 Mtr LoadLoss Motor Load Loss Warning
3 Mtr OvrVolt Motor Over Voltage Warning
4 MtrSlipRange Motor Slip out of Range Warning
5 Byp OvrVolt Bypass Over Voltage Warning
6 Byp UndrVolt Bypass Under Voltage Warning
7 Byp Unbal Bypass Voltage Unbalance Warning
8 Byp Phs Seq Bypass Phase Sequence Warning
9 SyncXferFail Synchronous Transfer Failed
10 Desync Delay De-synchronization delay Warning
11 Tach Loss Tach Loss Warning
12 Tach Dir Tach Direction is latched to the one before tach phase loss
13 TachPhA Loss Tach Phase A Loss Warning
14 No Tach No Tach Installed Warning
15 TachPhB Loss Tach Phase B Loss Warning
Control Power Fault Mask [Ctrl Pwr FltMask]
Linear Number: 104
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the fault mask for the various components used in protecting the control power
system feeding the drive. The following faults are maskable:
Bit Enum Text Description
0 ACDC#1DCFail Loss of 56V DC Power to DC/DC#1 Converter
1 ACDC#2DCFail Loss of 56V DC Power to DC/DC#2 Converter
2 ACDC#3DCFail Loss of 56V DC Power to DC/DC#3 Converter
3 ACDC#4DCFail Loss of 56V DC Power to DC/DC#4 Converter
4 Ctrl56V Loss Loss of 56V DC Control to DC/DC Converter
5 IGDPS56VLoss Loss of 56V DC Control to IGDPS
6 Ctrl5V Loss Loss of Non-Redundant 5V to DPM
7 Ctrl15V Loss Loss of Non-Redundant 15V to ACB
8 HECS PwrLoss Loss of control power to HECS Connectors
9 Ctrl PwrLoss 120V AC Control Power Loss
10 ACDC#1ACFail Loss of 120V AC Power to AC/DC#1 Power Supply
11 ACDC#2ACFail Loss of 120V AC Power to AC/DC#2 Power Supply
12 ACDC#3ACFail Loss of 120V AC Power to AC/DC#3 Power Supply
13 ACDC#4ACFail Loss of 120V AC Power to AC/DC#4 Power Supply
14 UPS Fault UPS Fault
15 Isol24V Loss Loss of Isolated 24V power supply
