Rockwell Automation PowerFlex 7000 Technical Data

Parameter Descriptions 2-87
7000-TD002A-EN-P – September 2007
Drive Fault Mask 1 [Drv Fault1 Mask]
Linear Number: 394
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the first fault word corresponding to drive protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
0 Line OvrCur Line Over Current Fault
1 DCLnkOvrCur DC Link Over Current Fault
2 Gnd OvrCur Ground Over current Fault
3 RNeut OvrCur Neutral Resistor Over Current Fault
4 Line OvrVolt Line Over Voltage Fault
5 Rec OvrVolt Rectifier Over Voltage Fault
6 LineNeuOvVol Line Neutral Over Voltage Fault
7 LineHarmonic Line Harmonic Fault
8 MstrVolUnBal Master Bridge Voltage Unbalance Fault
9 Slv1VolUnBal Slave1 Bridge Voltage Unbalance Fault
10 Slv2VolUnBal Slave2 Bridge Voltage Unbalance Fault
11 MstrCurUnBal Master Bridge Current Unbalance Fault
12 Slv1CurUnBal Slave1 Bridge Current Unbalance Fault
13 Slv2CurUnBal Slave2 Bridge Current Unbalance Fault
14 Slv1 Phasing Slave1 Bridge Phasing fault
15 Slv2 Phasing Slave2 Bridge Phasing fault
Drive Fault Mask 2 [Drv Fault2 Mask]
Linear Number: 395
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the second fault word corresponding to drive protection. A ‘1’
represents an enabled fault; a ‘0’ represents a disabled fault. The bit assignment is:
Bit Enum Text Description
0 RecAnaSlfTst Rectifier Analog Self Test Fault
1 RecFbrOptCfg Rectifier Fiber Optic Configuration Fault
2 Unused
3 Rec A2D Conv Rectifier Analog to Digital Converter Fault
4 InvHeartbeat Inverter Heartbeat Fault
5 Unused
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
